PDC500001 125MHZ 5032mm XO振荡器 Diodes 2.5V

频率：125MHZ

尺寸：5.0*3.2mm

PDC500001 125MHZ 5032mm XO振荡器 Diodes 2.5V，尺寸为5032mm,频率为125MHZ,频率稳定度为±50ppm,百利通亚陶晶振,XO时钟振荡器,SPXO振荡器，有源贴片晶振，5032mm晶振,Diodes晶振,台产晶振,智能手机晶振,SMD振荡器,低抖动晶振，网络设备晶振，视频系统晶振，无线模块晶振，罗拉模块晶振，PDA000001晶振，PDF550002晶振。PDC500001 125MHZ 5032mm XO振荡器 Diodes 2.5V.

PD振荡器系列是需要低抖动的高速应用程序的理想选择，包括：1/10千兆以太网2/4/10G光纤通道串行连接SCSI（SAS）服务器和存储平台SONET/SDH线卡无源光网络（PON）设备高清视频系统.

订购热线：0755-27838351

Japan1

Japan2

PDC500001 125MHZ 5032mm XO振荡器 Diodes 2.5V 参数表

Parameter Min. Typ. Max. Units Notes

Output Frequency

38.88

162

MHz

As specified

Supply Voltage

2.25

2.50

2.75

Supply Current, enabled

Supply Current, Disabled

0.03

Frequency Stability

±20 to ±50

ppm

See Note 1 below

Operating Temperature Range

--20

+70

°C

Commercial (standard)

--40

+85

Industrial (standard)

Output Logic 0, VOL

VCC - 1.62

Output Logic 1, VOH

VCC - 1.025

Output Load

50Ω connected connected to VCC - 2 V

output requires termination

Duty Cycle

measured 50% of waveform

Rise and Fall Time

500

850

measured 20/80% of waveform

Jitter, Phase

0.5

ps RMS (1- σ)

12kHz to 20MHz frequency band

Jitter, Total

ps pk–pk

100,000 random periods

Parameter

Min.

Typ.

Max.

Units

Notes

Input Voltage (pin OE), Output Enable

0.7

or open

Input Voltage (pin OE), Output Disable (low power standby)

0.3

Outpus disabled to Hi-Z

Internal Pullup Resistance

kΩ

Output Disable Delay

200

Output Enable Delay

PDC500001 125MHZ 5032mm XO振荡器 Diodes 2.5V 尺寸图

PDC500001晶振特点

38.88至162MHz频率范围

采用非PLL设计时，均方根抖动小于1ps

专为标准回流和清洗而设计，技术

提供IBIS型号

无铅且符合RoHS/绿色标准

更多相关百利通亚陶晶振型号

台产晶振原厂代码	品牌	型号	频率	频率稳定度	工作温度
PDF620008Z	Diodes晶振	SaRonix-eCera™ PD	156.25MHz	±50ppm	-40°C ~ 85°C
PDF620004	Diodes晶振	SaRonix-eCera™ PD	156.25MHz	±50ppm	-40°C ~ 85°C
PD5000002	Diodes晶振	SaRonix-eCera™ PD	50MHz	±50ppm	-20°C ~ 70°C
PD5000004	Diodes晶振	SaRonix-eCera™ PD	50MHz	±50ppm	-20°C ~ 70°C
PD6250003	Diodes晶振	SaRonix-eCera™ PD	62.5MHz	±50ppm	-20°C ~ 70°C
PD7500001	Diodes晶振	SaRonix-eCera™ PD	75MHz	±50ppm	-20°C ~ 70°C
PD7770001	Diodes晶振	SaRonix-eCera™ PD	77.76MHz	±50ppm	-20°C ~ 70°C
PDA620003	Diodes晶振	SaRonix-eCera™ PD	106.25MHz	±50ppm	-20°C ~ 70°C
PDC500003	Diodes晶振	SaRonix-eCera™ PD	125MHz	±50ppm	-20°C ~ 70°C
PDF000003	Diodes晶振	SaRonix-eCera™ PD	150MHz	±50ppm	-20°C ~ 70°C
PDF550003	Diodes晶振	SaRonix-eCera™ PD	155.52MHz	±50ppm	-20°C ~ 70°C
PDF620003	Diodes晶振	SaRonix-eCera™ PD	156.25MHz	±50ppm	-20°C ~ 70°C
PDF930002	Diodes晶振	SaRonix-eCera™ PD	159.375MHz	±50ppm	-20°C ~ 70°C
PDG110003	Diodes晶振	SaRonix-eCera™ PD	161.133MHz	±50ppm	-20°C ~ 70°C
PD5000001	Diodes晶振	SaRonix-eCera™ PD	50MHz	±50ppm	-40°C ~ 85°C
PD6250002	Diodes晶振	SaRonix-eCera™ PD	62.5MHz	±50ppm	-40°C ~ 85°C
PD7500002	Diodes晶振	SaRonix-eCera™ PD	75MHz	±50ppm	-40°C ~ 85°C
PD7770002	Diodes晶振	SaRonix-eCera™ PD	77.76MHz	±50ppm	-40°C ~ 85°C
PDA000001	Diodes晶振	SaRonix-eCera™ PD	100MHz	±50ppm	-40°C ~ 85°C
PDA620001	Diodes晶振	SaRonix-eCera™ PD	106.25MHz	±50ppm	-40°C ~ 85°C
PDC500001	Diodes晶振	SaRonix-eCera™ PD	125MHz	±50ppm	-40°C ~ 85°C
PDF000002	Diodes晶振	SaRonix-eCera™ PD	150MHz	±50ppm	-40°C ~ 85°C
PDF550001	Diodes晶振	SaRonix-eCera™ PD	155.52MHz	±50ppm	-40°C ~ 85°C
PDF930001	Diodes晶振	SaRonix-eCera™ PD	159.375MHz	±50ppm	-40°C ~ 85°C
PDG110001	Diodes晶振	SaRonix-eCera™ PD	161.133MHz	±50ppm	-40°C ~ 85°C
PD6250001	百利通亚陶晶振	SaRonix-eCera™ PD	62.5MHz	±25ppm	-20°C ~ 70°C
PDA000003	Diodes晶振	SaRonix-eCera™ PD	100MHz	±25ppm	-20°C ~ 70°C
PDA620002	Diodes晶振	SaRonix-eCera™ PD	106.25MHz	±25ppm	-20°C ~ 70°C
PDC500002	Diodes晶振	SaRonix-eCera™ PD	125MHz	±25ppm	-20°C ~ 70°C
PDF550002	Diodes晶振	SaRonix-eCera™ PD	155.52MHz	±20ppm	-20°C ~ 70°C
PDF620002	Diodes晶振	SaRonix-eCera™ PD	156.25MHz	±20ppm	-20°C ~ 70°C
PDG110002	Diodes晶振	SaRonix-eCera™ PD	161.133MHz	±20ppm	-20°C ~ 70°C
PDA000002	Diodes晶振	SaRonix-eCera™ PD	100MHz	±50ppm	-20°C ~ 70°C
PD5000003	Diodes晶振	SaRonix-eCera™ PD	50MHz	±50ppm	-40°C ~ 85°C
