SMD石英晶振超级适合北斗模块应用Q22FA23V0047716，爱普生公司敢于面对所有的困难与挑战，并且始终坚持将最好的品质，带给每一位客户，通过自身的能力，持续创造优质的晶振产品，以及更新迭代自身的产品，开发新型的无源晶振非常适合智能家居，通信设备等领域，产品均采用先进的生产技术，并结合当下高端设备制造而成。

产品编码	爱普生晶振	型号	频率	负载	Freq.tol. @+25°C	Freq.tol./Temp.range	Temperature range	ESR [Max]
Q22FA23V0042516	3.2 x 2.5 x 0.7mm	FA-238V	12.500000 MHz	7 pF	+/-50 ppm	+/-30 ppm	-20 to +70 °C	≤ 100 Ω
Q22FA23V0042616	3.2 x 2.5 x 0.7mm	FA-238V	14.745600 MHz	10 pF	+/-50 ppm	+/-30 ppm	-40 to +85 °C	≤ 80 Ω
Q22FA23V0043116	3.2 x 2.5 x 0.7mm	FA-238V	14.318180 MHz	8 pF	+/-20 ppm	+/-30 ppm	-20 to +70 °C	≤ 80 Ω
Q22FA23V0043216	3.2 x 2.5 x 0.7mm	FA-238V	12.000000 MHz	22 pF	+/-50 ppm	+/-30 ppm	-20 to +70 °C	≤ 100 Ω
Q22FA23V0043416	3.2 x 2.5 x 0.7mm	FA-238V	12.800000 MHz	15 pF	+/-50 ppm	+/-30 ppm	-20 to +70 °C	≤ 100 Ω
Q22FA23V0043616	3.2 x 2.5 x 0.7mm	FA-238V	13.000000 MHz	13 pF	+/-30 ppm	+/-30 ppm	-20 to +70 °C	≤ 100 Ω
Q22FA23V0043716	3.2 x 2.5 x 0.7mm	FA-238V	12.300000 MHz	10 pF	+/-50 ppm	+/-30 ppm	-40 to +85 °C	≤ 100 Ω
Q22FA23V0043916	3.2 x 2.5 x 0.7mm	FA-238V	12.000000 MHz	18 pF	+/-50 ppm	+/-30 ppm	-40 to +85 °C	≤ 100 Ω
Q22FA23V0044116	3.2 x 2.5 x 0.7mm	FA-238V	12.288000 MHz	12 pF	+/-20 ppm	+/-30 ppm	-20 to +70 °C	≤ 100 Ω
Q22FA23V0044816	3.2 x 2.5 x 0.7mm	FA-238V	13.333000 MHz	7 pF	+/-50 ppm	+/-30 ppm	-20 to +70 °C	≤ 80 Ω
Q22FA23V0045116	3.2 x 2.5 x 0.7mm	FA-238V	12.288000 MHz	10 pF	+/-50 ppm	+/-50 ppm	-40 to +85 °C	≤ 100 Ω
Q22FA23V0045216	3.2 x 2.5 x 0.7mm	FA-238V	12.000000 MHz	7 pF	+/-50 ppm	+/-30 ppm	-20 to +70 °C	≤ 100 Ω
Q22FA23V0045916	3.2 x 2.5 x 0.7mm	FA-238V	12.000000 MHz	12 pF	+/-20 ppm	+/-30 ppm	-20 to +95 °C	≤ 100 Ω
Q22FA23V0046516	3.2 x 2.5 x 0.7mm	FA-238V	14.318000 MHz	33 pF	+/-50 ppm	+/-50 ppm	-20 to +70 °C	≤ 80 Ω
Q22FA23V0046716	3.2 x 2.5 x 0.7mm	FA-238V	12.500000 MHz	16 pF	+/-30 ppm	+/-30 ppm	-20 to +70 °C	≤ 100 Ω
Q22FA23V0047716	3.2 x 2.5 x 0.7mm	FA-238V	12.000000 MHz	12 pF	+/-100 ppm	+/-30 ppm	-20 to +70 °C	≤ 100 Ω
Q22FA23V0048116	3.2 x 2.5 x 0.7mm	FA-238V	14.920000 MHz	10 pF	+/-50 ppm	+/-30 ppm	-20 to +70 °C	≤ 80 Ω
Q22FA23V0048216	3.2 x 2.5 x 0.7mm	FA-238V	12.000000 MHz	12.5 pF	+/-30 ppm	+/-30 ppm	-40 to +85 °C	≤ 100 Ω
Q22FA23V0048416	3.2 x 2.5 x 0.7mm	FA-238V	12.000000 MHz	18 pF	+/-20 ppm	+/-20 ppm	-30 to +85 °C	≤ 80 Ω
Q22FA23V0048516	3.2 x 2.5 x 0.7mm	FA-238V	12.000000 MHz	12 pF	+/-10 ppm	+/-20 ppm	-10 to +95 °C	≤ 100 Ω

SMD石英晶振超级适合北斗模块应用Q22FA23V0047716，爱普生品牌系列千赫子的石英贴片晶振,目前占据了中国市场进口晶25％的份额,品牌质量,货期,品种,品质是广大用户有目共睹,从FA-238V晶振最早期从MP4,MP3收音机模块启用开始,在到国内外各大知名品牌手机,最后应用到国内山寨手机市场。
