领先同行SMI高品质石英晶振选型一览表，SMI INC.一直以来在晶体行业处于领先者的位置，致力于走在技术的最前沿，同时在技术方面的造诣也十分深厚，并通过自身的对于技术与品质的追求，凭借着自身强大的信念，最终创造出来大量高品质石英晶振产品，而在技术方面了也有了极大的突破，能够快速打磨出适合各个领域发展的高质量高性能产品，以满足不同用户的需求，同时也为用户提供完美的晶振解决方案。
在成全自我的同时也是成功实现自我的价值最大化，随之持续不断深耕晶体行业，并竭尽自身的能力，为行业持续不断贡献自身价值，开创更多高质量低成本的晶振产品，以此赢得广大用户的支持与信赖，也为高新科技提供极好的选择空间。
领先同行SMI高品质石英晶振选型一览表
SMI is a rising leader of Crystal Technology.
We actively contribute to the electronics society, speedily developing advanced crystal products on the basis of steady researches and efforts.
We are specialized in the newest SMD versions of crystal units, clock OSC, TCXO, VCXO, OCXO & MCF. and supply products of high quality and high stability backed by highly reliable data in the frequencies from 16.000kHz (low) to 350.000MHz (high) , strict quality control and severe shipping inspection.
In addition to SMD versions, we can supply products of a thru-hole type.
Further, we are ready to meet special specifications as far as possible. So, please inquire of us anything without hesitation.
Please look over our products introduction, catalog and new products which are provided below.
| Photo | Package |
W x D x H (mm) |
Frequency (MHz) |
Freq. Tolerance (+25℃ ppm) |
Freq. Stability O.T. (ppm) |
Load Capacitance (pF,Typical) |
Ope. Temperature | |
|---|---|---|---|---|---|---|---|---|
|
11SMX |
|
1.2x1.6x0.3 | 24～80 | ±30 | ±30 | 7 | -20～+70℃ |
|
|
11SMX Custom |
|
1.2x1.6x0.3 | 24～80 | ±10～±20 | ±3～±150 | tba | tba |
|
|
21SMX |
|
1.6x2.0x0.45 | 20～80 | ±30 | ±30 | 8 | -20～+70℃ |
|
|
21SMX Custom |
|
1.6x2.0x0.45 | 20～80 | ±10～±20 | ±3～±150 | tba | tba |
|
22SMX |
|
2.0x2.5x0.5 | 16～80 | ±30 | ±30 | 8 | -20～+70℃ |
|
|
22SMX Custom |
|
2.0x2.5x0.5 | 16～80 | ±10～±20 | ±3～±150 | tba | tba |
.png)
|
32SMX(A) |
|
2.5x3.2x0.65 | 9.843～150 | ±30 | ±30 | 10 | -20～+70℃ |
|
|
32SMX(A) Custom |
|
2.5x3.2x0.65 | 9.843～150 | ±10～±20 | ±3～±150 | tba | tba |
.png)
|
53SMX(B) |
|
3.2x5.0x0.85 | 10～300 | ±50 | ±50 | 14 | -20～+70℃ |
|
|
53SMX(B) Custom |
|
3.2x5.0x0.85 | 10～300 | ±10～±20 | ±3～±150 | tba | tba |
.png)
|
53SMX(C) |
|
3.2x5.0x1.1/1.3 | 8～60 | ±50 | ±50 | 14 | -20～+70℃ |
.png)
|
53SMX(D) |
|
3.2x5.0x1.1 | 8～50 | ±50 | ±50 | 14 | -20～+70℃ |
.png)
|
97SMX(A) |
|
3.5x6.0x1.0 | 9～150 | ±50 | ±50 | 16 | -20～+70℃ |
.png)
|
97SMX(B) |
|
3.5x6.0x0.9 | 12～50 | ±50 | ±50 | 16 | -20～+70℃ |
.png)
|
97SMX(C) |
|
3.5x6.0x1.2 | 10～67 | ±50 | ±50 | 16 | -20～+70℃ |
.png)
|
94SMX(B) |
|
5.0x7.0/7.5x1.1 | 8～100 | ±50 | ±50 | 16 | -20～+70℃ |
|
|
94SMX(B) Custom |
|
5.0x7.0/7.5x1.1 | 8～100 | ±10～±30 | ±3～±150 | tba | tba |
.png)
|
94SMX(C) |
|
5.0x7.0/7.5x1.1 | 6～70 | ±50 | ±50 | 16 | -20～+70℃ |
.png)
|
94SMX(D) |
|
5.0x7.0/7.5x1.1 | 6～70 | ±50 | ±50 | 16 | -20～+70℃ |
.png)
|
93SMX(A) |
|
4.5x8.0x1.8 | 4～50 | ±50 | ±50 | 16 | -20～+70℃ |
.png)
|
93SMX(B) |
|
4.5x8.0x2.0 | 4～8 | ±50 | ±50 | 16 | -20～+70℃ |
.png)
|
92SMX(CN) |
|
5.5x11.8x1.5/1.8 | 3.579545～30 | ±50 | ±50 | 16 | -20～+70℃ |
.png)
|
92SMX(D) |
|
5.0x11.0x2.1 | 3.579545～40 | ±50 | ±50 | 16 | -20～+70℃ |
.png)
|
86SMX(LPN) |
|
4.3x12.4x3.6 | 3.579545～32 | ±50 | ±50 | 16 | -20～+70℃ |
.png)
|
86SMX(CSM) |
|
5.1x12.8x5.1/4.2 | 3.579545～32 | ±50 | ±50 | 16 | -20～+70℃ |
|
4HLB |
|
4.7x12.4x4.3 | 3.579545～80 | ±50 |
±50(AT) ±100(BT) |
18 |
-20～+70℃(AT) -10～+60℃(BT) |
|
3HLB |
|
4.7x12.4x3.2 | 3.579545～80 | ±50 |
±50(AT) ±100(BT) |
18 |
-20～+70℃(AT) -10～+60℃(BT) |
|
25HLB |
|
4.7x12.4x2.6 | 3.579545～80 | ±50 |
±50(AT) ±100(BT) |
18 |
-20～+70℃(AT) -10～+60℃(BT) |
|
HC-49/U-2H |
|
5.0x10.5x2.1 | 3.579545～61 | ±50 | ±50 | 16 | -20～+70℃ |
|
HC-49/U-3H |
|
5.0x10.5x2.5 | 3.579545～61 | ±50 | ±50 | 16 | -20～+70℃ |
|
HC-49/U-4H |
|
5.0x10.5x3.5 | 3.579545～61 | ±50 | ±50 | 16 | -20～+70℃ |
|
UM-1(MJ) UM-1S(MJ) |
|
7.8x8.0x3.1/2.8 | 6～200 | ±5～±20 | ±10～±30 | 16 | -20～+70℃ |
|
UM-5(MJ) UM-5S(MJ) |
|
5.8x8.0x3.1/2.8 | 10～200 | ±5～±20 | ±10～±30 | 16 | -20～+70℃ |
|
UM-4(MJ) UM-4S(MJ) |
|
4.4x8.0x3.1/2.8 | 20～200 | ±5～±20 | ±10～±30 | 16 | -20～+70℃ |
|
UM-1 UM-1S |
|
8.0x7.9x3.2/2.7 |
1～1.2 6～200 |
±3～±50 | ±10～±100 | 16 |
-10～+60℃(SL-Cut) -20～+70℃(AT-Cut) |
|
UM-5 UM-5S |
|
6.0x7.9x3.2/2.7 | 10～200 | ±3～±20 | ±10～±50 | 16 | -20～+70℃ |
|
UM-4 UM-4S |
|
4.5x7.9x3.2/2.7 | 20～200 | ±3～±20 | ±10～±50 | 16 | -20～+70℃ |
|
|
HC-49/U(MJ) HC-49/UT(MJ) |
|
13.5/11.5x11.5x4.8 | 1.8432～200 | ±5～±50 | ±10～±50 | 20 |
-10～+60℃ -20～+70℃ |
|
HC-49/U HC-49/UT |
|
13.5/11.2x11.3x4.9 | 1.8432～200 | ±5～±50 | ±10～±50 | 20 |
-10～+60℃ -20～+70℃ |
SMI是一个正在崛起的晶体技术领导者。
我们积极为电子社会做贡献，在不断研究和努力的基础上，快速开发先进的石英晶体产品。
我们专门从事最新的晶体单位，时钟振荡器，TCXO，VCXO，OCXO和MCF的SMD版本。并以16.000kHz(低)至350.000MHz(高)的高可靠数据、严格的质量控制和严格的装运检验为后盾，提供高质量和高稳定性的产品。
除了SMD版本，我们还可以提供通孔类型的产品。
此外，我们准备尽可能满足特殊规格。因此，请毫不犹豫地询问我们任何事情。
请仔细阅读我们的产品介绍，目录和下面提供的新产品。
Package
PDF
W x D x H
(mm)
Frequency
(kHz)
Freq. Tolerance
(+25℃ ppm)
Freq. Stability
O.T.
(ppm)
Load Capacitance
(pF,Typical)
Ope. Temperature
110SMX
1.0x1.6x0.5
32.768
±10～±30
-
7, 9, 12.5
-40～+85℃
212SMX
1.2x2.0x0.55
32.768
±10～±30
-
6, 7, 9, 12.5
-40～+85℃
31SMX
1.5x3.2x0.8
32.768
±5～±30
-
6, 7, 9, 12.5
-40～+85℃(Standard)
-40～+105℃(Option)
-40～+125℃(Option)
415SMX
1.5x4.1x0.9
32.768
±20～±30
-
7,9,12.5
-40～+85℃
52SMX
1.8x4.9x1.0
32.768
±20～±50
-
7, 9, 12.5
-40～+85℃
124SMX
1.5x7.0x1.4
32.768
±5～±30
-
3.7, 4.4, 6, 7, 9, 12.5
-40～+85℃
.png)
90SMX(N)
3.7x7.9x2.4
32.768
±5～±30
-
6, 12.5
-40～+85℃
.png)
90SMX(S)
3.7x8.7x2.5
32.768
±5～±30
-
6, 12.5
-40～+85℃
mj.png)
26(LF)MJ
2.5x8.3x2.2
32.768
±15～±50
-
12.5
-40～+85℃
.png)
26(LF)
2.0x9.0(WxD)
32.768
±15～±50
-
8, 10, 12.5
-40～+85℃
1.2x4.7mm
1.2x4.7(WxD)
32.768
±10～±30
-
8
-20～+60℃
1.4x5mm
1.4x5(WxD)
32.768
±10～±30
-
8
-20～+70℃
2x6mm
2x6(WxD)
32.768
±10～±30
-
12.5
-20～+70℃
3x8mm
3x8mm
32.768
±10～±30
-
12.5
-20～+70℃
